2-6 3120656
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
— — — — — — — — — —
1701428 Nametag - 1 1
1701426 Nametag - 3 1
1701463 Nametag - 4 1
1701462 Nametag - 5 1
1701778 Nametag - 6
0251415 HAND PUMP INSTALLATION (USE WITH
OPTIONAL MANUAL DESCENT) Ref. C
54 3600179 Pump, Manual with Handle (Includes Item 59) 1
7016673 Pump, Manual - w/o Handle 1
2900779 Seal Kit
55 0641609 Bolt 3/8”-16NC x 1 1/8” 2
56 4751600 Flatwasher 3/8” 2
57 4761600 Lockwasher 3/8” 2
58 3311601 Nut 3/8”-16NC 2
59 7010652 Handle, Pump 1
60 1380136 Clip, Gripper 2
61 3941003 Screw, Self-Tapping #10 2
62 4640603 Valve, Relief 1
2900770 Seal Kit
63 0641414 Bolt 1/4”-20NC X 1 3/4” 1
64 4751400 Flatwasher 1/4” 1
65 4761400 Lockwasher 1/4” 1
66 3311401 Nut 1/4”-20NC 1
0255504 TILT INDICATOR INSTALLATION - 4WD BUILT
AFTER JANUARY 1995 ONLY Ref. A
67 4360386 Sensor, Level - 8.5° 1
2820032 Tubing, Vinyl 6 in./15cm
4300106 Stud, Grooved 2
FIGURE 2-1. CONTROL VALVES INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
