1-4 3120656
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
13 4843271 Pin (Standard) 1
3421836 Pin (CSA) 1
14 3450814 Pin, Cotter 1/4” x 3 1/2” 1
15 4740158 Washer, Thrust 2
16 0641608 Bolt 3/8”-16NC x 1” 1
4740185 Flatwasher, Hardened 1
17 0961029 Bushing (Spindle Pivot Point) (4WD) (Prior to
February 1994 to Present) 4
18 0961003 Bushing (Axle Pivot Point) (Prior to February 1994) 2
0961771 Bushing (Axle Pivot Point) (February 1994 to
Present)
2
19 4220098 Stop, Axle 2
20 3311801 Nut 1/2”-13NC 4
21 4761800 Lockwasher 1/2” 4
22 4751800 Flatwasher 1/2” 4
4300045 Stud (Welded on Part) 4
23 4070528 Shim, Stop A/R
4070800 Shim, Stop (.125) A/R
24 3311601 Nut 3/8”-16NC 4
25 4761800 Lockwasher 12” 4
26 4751800 Flatwasher 4
4300034 Stud (Welded on Part) 4
27 1320125 Clamp 1
28 3311601 Nut 3/8”-16NC 1
29 4761600 Lockwasher 3/8” 1
4300030 Stud (Welded on Part) 1
30 2160002 Fitting, Grease 3
31 2160003 Fitting, Grease - 45° 1
32 3780184 O-Ring 2
0236449 STEERING AND SPINDLES INSTALLATION
(STANDARD 2WD) Ref. O
0251521 STEERING AND SPINDLES INSTALLATION (CSA
2WD) Ref. F
33 1681562 Steer Cylinder Assembly (See Section 5 for
Breakdown) 1
34 3431622 Pin, Clevis 1
35 4712600 Flatwasher 1
36 3450606 Pin, Cotter 1
37 0440091 Washer, Thrust 1
38 3300175 Locknut, Special 1
39 2160003 Fitting, Grease - 45° 2
40 3840863 Rod, Tie 1
41 0560714 Block, Tie Rod (Left Side) 1
0560605 Block, Tie Rod (Right Side) 1
42 3300229 Nut, Jam (Left Side) 1
3323002 Nut, Jam (Right Side) 1
43 0630425 Bolt, Special 2
44 0440091 Washer, Thrust 2
FIGURE 1-1. FRAME, STEERING AND AXLE INSTALLATIONS - 2WD AND 4WD (WITH 2 WHEEL
STEER) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
