JLG 60HA ANSI Parts Manual User Manual
Page 170

2-98
3120656
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
7
2180467
Fitting, 90°
2
0100020
Sealant
A/R
8
1320022
Clamp
2
9
4562516
Tube, Sight
26 in.
10
2200052
Plug, Pipe - 1/4”
1
2200223
Plug, Pipe - 1/2” (0255604 Installation Only - Not
Shown)
A/R
11
3311505
Locknut 5/16”-18NC
4
12
4761500
Lockwasher 5/16”
4
13
4751500
Flatwasher 5/16”
4
4300073
Stud (Welded on Part)
4
0641514
Bolt 5/16”-18NC x 1 3/4”
A/R
14
4070410
Shim (1/16”)
A/R
4070411
Shim (1/8”)
A/R
4070412
Shim (3/16”)
A/R
— — — — — — — — — —
4400266
Hydraulic Tank Assembly (Standard)
1
C
4400291
Hydraulic Tank Assembly (With Heater)
1
B
15
4400265
Hydraulic Tank Weldment (Standard)
1
4400290
Hydraulic Tank Weldment (With Heater)
1
16
1670468
Lid
1
17
3311401
Nut 1/4”-20NC
14
18
4761400
Lockwasher 1/4”
14
A
19
4751400
Flatwasher 1/4”
14
20
3960371
Gasket
1
-
21
2120103
Filter, Return (Includes Item 26)
1
7004244
Indicator, Pressure
1
7012559
Gasket (Between the Filter & Tank)
1
7016333
O-Ring (Under Cap)
1
22
0641612
Bolt 3/8”-16NC x 1 1/2”
4
23
4761600
Lockwasher 3/8”
4
24
4740322
Washer, Sealing
4
25
3311601
Nut 3/8”-16NC
4
26
2120107
Element (Part of Item 21)
1
27
1340045
Filler, Strainer
1
4740338
Washer, Sealing
6
28
2180467
Fitting, 90°
2
0100020
Sealant
A/R
29
1320022
Clamp
2
30
4562516
Tube, Sight
26 in.
31
2120104
Filter, Suction
1
0100020
Sealant
A/R
32
3520022
Plug - 3/4”
1
0100020
Sealant
A/R
33
2180527
Plug - 1/16”
1
0100020
Sealant
A/R
34
2200268
Fitting, Coupling
1
0100020
Sealant
A/R
35
2180711
Pipe, Return
1
36
1600043
Controller, Thermostat (With Heater Only)
1
FIGURE 2-26. TANKS INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
