2-56 3120656
SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
23 1660183 Coupling Assembly - Hayes (Design B) 1
24 0641607 Bolt 3/8”-16NC x 7/8” 6
4761600 Lockwasher 3/8” 6
25 0080163 Adapter, Pump 1
26 0641610 Bolt 3/8”-16NC x 1 1/4 8
27 4761600 Lockwasher 3/8” 8
— — — — — — — — — —
28 3600139 Pump Assembly - Gear (See Figure 2-25 for Break-
down) 1
29 0641812 Bolt 1/2”-13NC x 1 1/2” 4
30 4761800 Lockwasher 1/2” 4
31 0901401 Bracket, Terminal Strip 1
1670414 Cover, Strip 1
32 1700901 Decal - Terminal Strip Label 1
33 1320070 Clamp, Wiring 2
3910812 Screw, Round Head #8-32NC x 3/4” 1
4770800 Starwasher #8 1
3310801 Nut #8-32NC 1
34 3980003 Masonite 1
35 0400025 Battery - 13” Length 1
0400003 Battery - 10” Length 1
36 0400002 Holddown (Design A) 1
2910479 Clips Holddown (Design A) 2
37 0361810 Holddown (Design B) 1
38 0236768 Rod, Tie Down - 11” Rod 2
3841026 Rod, Tie Down - 10” Rod 2
39 4751600 Flatwasher 3/8” 2
40 3300029 Wingnut 3/8”-16NC 2
— — — — — — — — — —
41 1060093 Cable, Battery (Positive to Aux. Relay) (19” Length) 1
1060129 Cable, Battery (Positive to Aux. Relay) (40” Length) 1
1060119 Cable, Battery (Positive to Aux. Relay) (48” Length) 1
42 1060093 Cable, Battery (Negative to Ground) (13” Length) 1
1060172 Cable, Battery (Negative to Ground) (18” Length) 1
43 1060045 Cable, Battery (Engine to Ground) 1
44 1060129 Cable, Battery (Aux. Relay to Aux. Power) 1
45 1060092 Cable, Battery (Aux. Relay to Start Relay) 1
46 1060099 Cable, Battery (Starter to Start Relay) 1
47 0181488 Angle, Radiator Support (Front) 1
48 0641408 Bolt 1/4”-20NC x 1” 1
49 4751400 Flatwasher 1/4” 1
50 4761400 Lockwasher 1/4” 1
51 3311401 Nut 1/4”-20NC 1
52 3620026 Radiator (Specify when ordering: Modine or Long) 1
53 0630360 Bolt, Carriage 5/16”-18NC x 1 1/4” 2
54 4761500 Lockwasher 5/16” 3
55 3311501 Nut 5/16”-18NC 3
56 0630375 Bolt, Carriage 7/16”-14NC x 1” 2
57 4751700 Flatwasher 7/16” 2
FIGURE 2-16. FORD LSG423 ENGINE INSTALLATIONS - WITHOUT NOISE REDUCTION (PRIOR TO
FEBRUARY 1993) (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
