SECTION 2 TURNTABLE
S
E
C
T
I
O
N
2
T
U
R
N
T
A
B
L
E
32 (cont’d)
7010635
Cartridge without Coil (Hydraforce Version)
1
7003635
Cartridge, Check Valve (Vickers/Modular Controls
Version)
1
7010637
Seal Kit (Hydraforce Version)
1
33
3311501
Nut 5/16”-18NC
4
34
4761500
Lockwasher 5/16”
2
35
4751500
Flatwasher 5/16”
4
4300033
Stud (Welded on Part)
2
36
4640603
Valve, Pilot Operated Relief
1
2900770
Seal Kit
1
37
3311401
Nut 1/4”-20NC
2
38
4761400
Lockwasher 1/4”
2
39
4751400
Flatwasher 1/4”
2
4300042
Stud (Welded on Part)
2
40
4640626
Valve, Counterbalance
1
7011339
Cartridge Valve
1
2900770
Seal Kit
1
41
3311401
Nut 1/4”-20NC
2
42
4761400
Lockwasher 1/4”
2
43
4751400
Flatwasher 1/4”
2
4300042
Stud (Welded on Part)
2
0239586
5° TILT INDICATOR INSTALLATION
Ref.
C
0251119
3° TILT INDICATOR INSTALLATION
Ref.
B
44
4360171
Sensor, Level - 5°
1
4360279
Sensor, Level - 3°
1
2820022
Tubing, Vinyl
6 in.
4300106
Stud, Grooved
2
45
Not Used
0239585
TURNTABLE LOCK INSTALLATION
Ref.
B
46
3421565
Pin, Snapper
1
47
3421565
Pin, Quick Release
2
1260017
Chain
9 in.
48
3421627
Pin, Lock
1
0251240
MANUAL DESCENT INSTALLATION - OPTIONAL
(PRIOR TO SEPTEMBER 1992)
Ref.
B
0253167
MANUAL DESCENT INSTALLATION - OPTIONAL
(SEPTEMBER 1992 TO PRESENT)
Ref.
B
49
4640005
Valve, Needle
A/R
2900062
Valve, Kit
4
50
0901732
Bracket
1
51
3311601
Nut 3/8”-16NC
2
52
4761600
Lockwasher 3/8”
2
53
4751600
Flatwasher 3/8”
2
4300034
Stud (Welded on Part)
2
FIGURE 2-1. CONTROL VALVES INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
