Page 18

1-10
3120656
SECTION 1 FRAME
S
E
C
T
I
O
N
1
F
R
A
M
E
28
3311601
Nut 3/8”-16NC
1
4761600
Lockwasher 3/8”
1
4300030
Stud (Welded on Parts)
1
29
2160002
Fitting, Grease
3
30
2160003
Fitting, Grease - 45°
1
31
0560951
Block, Axle (2WD with Fixed Front Axle)
2
32
0641616
Bolt 3/8”-16NC x 2”
4
4751600
Flatwasher 3/8”
4
33
4070224
Shim -.12
A/R
4070225
Shim -.06
A/R
0100019
Loctite #271
A/R
0254294
FIXED FRONT AXLE INSTALLATION - 4WD
Ref.
A
0251591
OSCILLATING FRONT AXLE INSTALLATION - 4WD
(DOMESTIC) (PRIOR TO SEPTEMBER 1992)
Ref.
C
0251916
OSCILLATING FRONT AXLE INSTALLATION - 4WD
(CSA) (PRIOR TO SEPTEMBER 1992)
Ref.
B
0253123
OSCILLATING FRONT AXLE INSTALLATION - 4WD
(SEPTEMBER 1992 TO PRESENT)
Ref.
D
34
Lockout Cylinder Assembly Options (4WD with
Oscillating Axle) (See Section 5 for Breakdown):
2
1681785
Cylinder (Prior to September 1992)
1682757
Cylinder (TUV) (September 1992 to Present)
35
3421861
Pin (Bottom)
2
36
4843286
Pin (Top)
2
37
0641407
Bolt 1/4”-20NC x 7/8”
4
38
4761400
Lockwasher 1/4”
4
39
4751400
Flatwasher 1/4”
4
40
4843826
Axle Weldment (4WD)
1
41
3422064
Pin (Domestic) (Prior to February 1994)
1
3422360
Pin (Domestic) (February 1994 to Present)
1
3421940
Pin (CSA) (Prior to February 1992) (Use 3422066 as
Replacement)
1
3422066
Pin (CSA) (February 1992 to September 1992)
1
3422064
Pin (CSA) (September 1992 to February 1994)
1
3422360
Pin (CSA) (February 1994 to Present)
1
3780187
O-Ring (September 1992 to Present Only) (Not
Shown)
2
42
0641610
Bolt 3/8”-16NC x 1 1/4”
1
43
4761600
Lockwasher 3/8”
1
44
4740185
Flatwasher, Hardened
1
45
0961529
Bushing, Bronze (Top) (Prior to May 1992)
2
0961686
Bushing, Bronze (Top) (May 1992 to February
1994)
2
0961776
Bushing, Bronze (Top) (February 1994 to Present)
2
46
0961509
Bushing, Bronze (Bottom) (Prior to May 1992)
2
0961687
Bushing, Bronze (Bottom) (May 1992 to February
1994)
2
FIGURE 1-2. FRAME, STEERING AND AXLE INSTALLATIONS - 2WD AND 4WD (WITH 4 WHEEL
STEER) (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
