3120656 5-5
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIGURE 5-2. AXLE LOCKOUT CYLINDER ASSEMBLY - 4WD/2WS (PRIOR TO SEPTEMBER 1992)
(USE WITH OPTIONAL OSCILLATING AXLE)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
1681571 AXLE LOCKOUT CYLINDER ASSEMBLY - 4WD/2WS
(PRIOR TO SEPTEMBER 1992) (USE WITH OPTIONAL
OSCILLATING AXLE) Ref. G
1 1681458 Barrel 1
2 4640273 Bleeder (Prior to April 1992) 2
3900175 Setscrew 1/4”-28NF x 3/4” (April 1992 to Present) 4
3960416 Seal, Thread (April 1992 to Present) 4
3321401 Nut 1/4”-28NF (April 1992 to Present) 4
3 3300187 Nut (Prior to April 1992) 1
3300273 Nut, Hex (August 1992 to Present) 1
4 3900141 Setscrew 1/4”-20NC x 3/8” A/R
3900170 Setscrew 3/8”-16NC x 3/8” A/R
5 Kit Seal 1
6 Kit O-Ring 1
7 Kit Ring, Wear 1
8 3480134 Piston 1
9 4562859 Spacer 1
10 Kit O-Ring 1
11 Kit Ring 1
12 1681322 Head 1
13 Kit Seal, Rod 1
14 Kit Seal, Wiper 1
15 1120108 Retainer, Head 1
16 1681460 Rod 1
17 2160002 Fitting, Grease (Prior to April 1992) 1
2160003 Fitting, Grease - 45° (April 1992 to Present) 1
— — — — — — — — — —
0100011 Loctite #242 A/R
0100038 Primer, Locking A/R
0100035 Loctite #222 A/R
— — — — — — — — — —
2901148 Kit, Seal (Includes Items 5, 6, 7, 10, 11, 13 and 14) 1
