SECTION 9 RECOMMENDED SERVICE PARTS STOCK
Model 60HA
The following lists will service fleets of machines (built to current production per date on the front cover with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-4 5-9 10 OR MORE
Ref. STANDARD PARTS
4360171 Sensor, Level - 5° (Figure 2-1) 1 1 1
7012339 Coil (Figure 2-3) 1 1 1
7000418 Coil (Figures 1-16, 2-5 and 2-7) 1 1 1
7002450 Coil (Figure 2-5) 1 1 1
2120107 Element, Hydraulic Oil (Figure 2-26) 4 8 12
1340046 Breather, Hydraulic OIl (Figure 2-26) 1 2 3
4360003 Switch, Key (Figure 2-28) 1 1 1
2860002 Key, Replacement (Figure 2-28) 1 1 1
4360073 Switch, Toggle (Figure 2-28) 1 1 1
4360199 Switch, Toggle (Figures 2-28 and 4-5) 1 1 1
4360202 Switch, Toggle (Figures 2-28 and 4-5) 1 1 1
4360200 Switch, Toggle (Figures 2-28 and 4-5) 1 1 1
3740049 Relay (Figure 2-28 and 4-5) 1 1 1
4360216 Breaker, Circuit (Figure 2-28) 1 1 1
4360232 Breaker, Circuit (Figure 2-28) 1 1 1
3740058 Relay (Figure 2-28) 1 1 1
3740059 Relay (Figure 2-28) 1 1 1
3740067 Relay (Figure 2-28) 1 1 1
4360274 Switch, Push Button (Figures 2-28 and 4-5) 1 1 1
1600110 Sensor, Level (Figure 3-1) 1 1 1
7006139 Powertrack - 1 Foot Section (Figures 3-2 and 3-3) 2 2 2
7006152 Pin Kit - Powertrack (Figures 3-2 and 3-3) 24 24 24
2940006 Latch, Platform Door (Figures 4-1 and 4-2) 1 1 1
4360031 Footswitch (Figures 4-1 and 4-2) 1 1 1
1600141 Controller, PQ (Figure 4-5) 1 1 1
7011907 Electrical Assembly - 1600141 Controller (Figure 4-5) 1 1 1
7003751 Potentiometer - 1600141 Controller (Figure 4-5) 1 1 1
4360289 Switch, Emergency Stop (Figure 4-5) 1 1 1
4360282 Block, Contact (Figure 4-5) 1 1 1
4360209 Breaker, Circuit (Figure 4-5) 1 1 1
3990010 Diode - 6 Amp (Figure 7-1) 2 2 2
Ref. VARIABLE PARTS
4360386 Switch, Level Sensor (4WD) (Figure 2-1) 1 1 1
1660184 Coupling, Engine (Deutz Machines) (Figure 2-14) 1 1 1
7016331 Engine Oil Filters (Deutz Machines) (Figure 2-14) 1 case 1 case 1 case
7020023 Engine Fuel Filters (Deutz Machines) (Figure 2-14) 1 1 1
7004214 Element, Air Cleaner (Ford and Deutz Machines) (Figures
2-14 and 2-20) 12 12 12
7012656 Coupling, Engine (Ford Machines) (Figure 2-20) 1 1 1
7021869 Engine Oil Filters (Ford Machines) (Figure 2-20) 1 case 1 case 1 case
3740080 Relay (Ford Machines) (Figure 2-20) 1 1 1
