JLG 60HA ANSI Parts Manual User Manual
Page 251
3120656
5-9
SECTION 5 CYLINDER
S
E
C
T
I
O
N
5
C
Y
L
I
N
D
E
R
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
AXLE LOCKOUT CYLINDER ASSEMBLIES - 4WD/
4WS (STANDARD PARTS) (USE WITH OPTIONAL
OSCILLATING AXLE)
Ref.
1
1681787
Rod
1
2
Not Used
3
1120179
Retainer
1
4
1680892
Head
1
5
3480120
Piston
1
6
3300187
Nut (Prior to April 1992)
1
3300273
Nut, Hex (April 1992 to Present)
1
7
4563647
Tube, Spacer
1
8
Kit
Seal, Wiper
1
9
Kit
Seal, Rod
1
10
Kit
Ring, Wear
1
11
Kit
O-Ring
1
12
Kit
Ring, Back-up
2
13
Kit
O-Ring
1
14
kIT
Seal, Piston
1
15
kIT
Ring, Wear
1
16
3900141
Setscrew 1/4”-20NC x 3/8” (Prior to April 1992)
2
3900170
Setscrew 38”-16NC x 3/8” (April 1992 to Present)
1
17
0100010
Loctite #242
A/R
18
3900175
Setscrew 1/4”-28NF x 3/4”
2
3960416
Seal, Thread
2
3321401
Nut 1/4”-28NF
2
Note: Replace existing bleeders with these
components when ordering parts.
Ref.
19
2160002
Fitting, Grease
2
20
0100035
Compound, Locking
A/R
21
0100038
Primer, Locking
A/R
— — — — — — — — — —
2900381
Seal Kit (Includes Items 8-15)
1
1681785
AXLE LOCKOUT CYLINDER ASSEMBLY (PRIOR TO
SEPTEMBER 1992) (VARIABLE PARTS)
Ref.
D
51
1681788
Barrel
1
1682757
AXLE LOCKOUT CYLINDER ASSEMBLY (SEPTEM-
BER 1992 TO PRESENT) (VARIABLE PARTS)
Ref.
A
51
1682758
Barrel
1
52
4640509
Valve, Holding
2
2900792
Seal Kit - 4640509 Valve
2
