SECTION 1 - FRAME
3121274 6RS/10RS/1932RS/3248RS 9
FIGURE 1-1. FRONT AXLE COMPONENTS (6RS/1932RS)
ITEM PART NUMBER QTY DESCRIPTION REV
1001133101 Ref STEERING INSTALLATION E
1 0440263 2 Bearing, Flanged
2 0760815 2 Bolt M8 x 35
3 3290805 2 Nut M8
4 3391210 1 Pin, Cotter
5 3431214 1 Pin, Clevis
6 3431222 1 Pin, Clevis
7 3450606 2 Pin, Cotter
8 3841147 2 Keeper, Pin
9 4811900 2 Washer M8
10 4812500 4 Washer M20
11 1001129754 1 Pin, Clevis
12 1001130160 2 Kingpin
13 4740217 2 Bearing, Thrust
14 1001132702 1 Steer Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
15 1001133086 2 Spindle Assembly B
15A 1001133085 2 Spindle (1 per Assembly)
15B 1001129368 4 Bearing (2 per Assembly)
15C 2780266 2 Hub Assembly (1 Per Assembly (See Items 101-108 for
Breakdown)
16 1001133115 1 Tie-Rod
2780266 Ref HUB ASSEMBLY D
Ref Note: Qtys shown for 1 Assembly. Two Assemblies required
per machine.
101 1001102354 1 Cap, Dust (was p/n 7012524)
102 3300423 1 Nut, Slotted (was p/n 7010641)
103 3450406 1 Pin, Cotter 2 x 3/16 (was p/n 7010642)
104 4740468 1 Washer (was p/n 7019697)
105 1001102351 1 Bearing, Cone - Outer (was p/n 7026185)
106 2780266 1 Hub (Includes Bearing Cups)
107 1001102353 1 Bearing, Cone - Inner (was p/n 7026183)
108 1001102349 1 Seal (was p/n 7026184)
1001133066 Ref TIRE AND WHEEL INSTALLATION A
Ref Note: Must replace Tire and Wheel Assy's in pairs per axle.
201 0630580 20 Bolt, Wheel
202 1001133065 4 Tire and Wheel Assembly
