SECTION 3 - SCISSOR ARMS
3121274
6RS/10RS/1932RS/3248RS
47
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
101
0440264
8
Bearing
102
0962140
40
Bearing
103
1001132472
1
Arm, Lower Outboard
104
1001132473
2
Arm, Mid Outboard
105
1001132474
1
Arm, Upper Outboard
106
1001132475
1
Arm, Lower Inboard
107
1001132476
1
Arm, Mid Inboard
108
1001132477
1
Arm, Upper Inboard
1001134809
Ref
LATCH ASSEMBLY
B
201
0100011
AR
Compound, Locking
202
4811700
1
Washer M6
203
0700627
1
Bolt M6 x 100
204
3290305
1
Nut M3
205
3290607
1
Nut M6
206
3423151
1
Pin, Plunger
208
1001110544
2
Washer M3
209
1001134811
1
Bracket
210
1001134813
1
Link
211
1001140670
1
Rod, Release
212
1001134833
1
Screw M3 x 40 (Stainless)
213
3450203
1
Pin, Cotter
