SECTION 1 - FRAME
14 6RS/10RS/1932RS/3248RS 3121274
ITEM PART NUMBER QTY DESCRIPTION REV
Ref USA Assembled Machines
1001158899 Ref Charger Only A
1001158900 Ref Charger with 110V Plug A
1001159006 Ref Charger with No Plug (Note: See ELECTRICAL SECTION for
Plug Options) A
301 0760610 AR Bolt M6 x 20
302 1321293 1 Clamp
303 3290605 AR Nut M6
304 4811700 AR Washer M6
305 Ref AC Cable Options:
305 1001103257 1 Cable with 110V Plug
305 1001172010 1 Cable with 420V Plug
305 1001103258 1 Cable with No Plug (Note: See ELECTRICAL SECTION for
Plug Options)
306 1001129847 1 Battery Charger Assembly (See ELECTRICAL SECTION for
Breakdown)
1001133066 Ref TIRE AND WHEEL INSTALLATION A
Ref Note: Must replace Tire and Wheel Assy's in pairs per axle.
401 0630580 20 Bolt, Wheel (5 Per Wheel)
402 1001133065 4 Tire and Wheel Assembly
