SECTION 1 - FRAME
3121274
6RS/10RS/1932RS/3248RS
27
FIGURE 1-7. INVERTER INSTALLATION (OPTIONAL)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001142170
Ref
INVERTER INSTALLATION (OPTIONAL)
C
1
0760408
4
Bolt M4 x 16
2
0760612
6
Bolt M6 x 25
3
3290405
4
Nut M4
4
3290605
5
Nut M6
5
3740150
1
Relay
5
4460891
1
Receptacle, Female - 2 Position
5
4460465
2
Socket, Female
6
4240017
12
Tie-Strap (Not Shown)
7
4360336
1
Switch, Toggle
8
1705305
NLA
Decal - Pressure Wash (Note: Use p/n 1001125483) (Prior to SN
02000226550, Prior to SN B200015665)
8
1001125483
1
Decal - Pressure Wash (SN 0200226550 to Present, SN
B200015665 to Present)
9
4811400
4
Washer M4
10
4811700
11
Washer, M6
11
1001130220
1
Retainer M6
12
1001136757
1
Inverter
13
1001142172
1
Bracket
14
1001142173
1
Insulate
15
1001142174
4
Washer
16
1001142176
1
Panel
17
1001143009
1
Decal - Inverter
18
1001143010
1
Decal - On/Off
19
1001138967
1
Cable (Battery + to Relay)
19
1001126833
1
Fuse - 80 Amp
19
1001125389
1
Fuseholder
20
1001145762
1
Cable (Inverter + to Relay)
21
1001145763
1
Harness, Inverter
21
4460418
1
Receptacle, Female - 6 Position
21
4460419
2
Terminal
21
4460897
1
Plug, Male - 2 Position
21
4460464
2
Pin, Male
22
1001145881
1
Harness - AC Extension
22
4460138
1
Plug, Male 3 Prong
22
4460968
1
Connector, Strain Relief
22
1001157513
1
Plug, Male - 3 Position
22
1001157790
3
Socket, Female
23
85941016
1
Clamp
24
1001157547
1
AC Filter Electrical Assembly
25
1001157645
1
Harness - AC Extension
25
4460779
1
Receptacle, Female - 3 Prong
100
1001161104
1
Inverter Installation Kit (Dealer Installed)
