SECTION 1 - FRAME
22
6RS/10RS/1932RS/3248RS
3121274
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
207
See Note
2
Bolt, Motor (Note: Use Item 309)
208
See Note
2
Lockwasher (Note: Use Item 309)
211
See Note
1
Bolt, Brake (Note: Use Item 307)
Ref
Kit Options
301
7024747
1
Gear box Cover Kit (Includes 11, 19, 20, 21 & 29)
302
7024748
1
Gearbox Main Seal Kit (Includes Qty 1 of Items 14, 16 & 20)
303
7024749
1
Input Carrier Kit (Includes Items 4-8, 18, 20 & 23-26)
304
7024758
1
Input Ring Kit (Includes Qty 1 of Items 3, 14, 20 & 27)
305
7024756
1
Gearbox Hub Kit 6RS/1932RS (Include Items 2, 14, 16, 20 & 27)
305
70003677
1
Gearbox Hub Kit 10RS/3248RS (Include Items 2, 14, 16, 20 &
27)
306
7024750
1
Gearbox Output Planet Kit (Includes Items 9, 10, 14, 15, 20, 25-
28 & 32)
307
70003678
1
Brake Kit (Includes Item 110, 111 & 211)
308
7024741
1
Motor Brush and Bearing Kit (Includes Items 104, 107 & 108)
309
70003681
1
Motor Mounting Kit 6RS/1932RS (Include Items 107 & 108)
309
70003679
1
Motor Mounting Kit 10RS/3248RS (Include Items 107 & 108)
310
70003682
1
Motor Kit 6RS/1932RS (Include Items 13 & 17)
310
70003680
1
Motor Kit 10RS/3248RS (Include Items 13 & 17)
311
70001265
1
Cover Kit (Includes Items 111 & 112)
