SECTION 1 - FRAME
18
6RS/10RS/1932RS/3248RS
3121274
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001131963
Ref
Charger with No Plug (Note: See ELECTRICAL SECTION for
Plug Options)
C
1001172009
Ref
Charger with 420V Plug
B
Ref
USA Assembled Machines
1001158899
Ref
Charger Only
A
1001158900
Ref
Charger with 110V Plug
A
1001159006
Ref
Charger with No Plug (Note: See ELECTRICAL SECTION for
Plug Options)
A
301
0760610
2
Bolt M6 x 20
302
1321293
1
Clamp
303
3290605
2
Nut M6
304
4811700
4
Washer M6
305
Ref
AC Cable Options:
305
1001103257
1
Cable with 110V Plug
305
1001172010
1
Cable with 420V Plug
305
1001103258
1
Cable with No Plug (Note: See ELECTRICAL SECTION for
Plug Options)
306
1001129847
1
Battery Charger Assembly (See ELECTRICAL SECTION for
Breakdown)
1001130486
Ref
TIRE AND WHEEL INSTALLATION
A
Ref
Note: Must replace Tire and Wheel Assy's in pairs per axle.
401
0630580
22
Bolt, Wheel (5 Per Front Wheel / 6 Per Rear Wheel)
402
1001127628
2
Tire and Wheel Assembly (Rear)
403
1001129621
2
Tire and Wheel Assembly (Front) (Not Shown)
