SECTION 1 - FRAME
3121274 6RS/10RS/1932RS/3248RS 11
FIGURE 1-2. FRONT AXLE COMPONENTS (10RS/3248RS)
ITEM PART NUMBER QTY DESCRIPTION REV
1001129400 Ref STEERING INSTALLATION C
1 07601015 2 Bolt M10 x 35
2 3291005 2 Nut M10
3 3291605 2 Nut M16
4 3391210 1 Pin, Cotter
5 3841143 2 Keeper, Pin
6 4740217 2 Bearing, Thrust
7 4812000 2 Washer M10
8 1001129302 2 Spindle Assembly D
8A 1001129301 2 Spindle (1 per Assembly)
8B 1001129368 4 Bearing (2 per Assembly)
8C 1001129381 2 Hub Assembly (1 Per Assembly (See Items 301-308 for
Breakdown)
9 1001129367 2 Bearing, Flanged
10 1001129742 1 Bolt M20 x 80
11 1001129743 1 Bolt M20 x 30
12 1001129754 1 Pin, Clevis
13 1001129940 1 Tie-Rod
14 1001133103 1 Steer Cylinder Assembly (See CYLINDER SECTION for
Breakdown)
15 1001130160 2 Kingpin
1001129381 Ref HUB ASSEMBLY A
Ref Note: Qtys shown for 1 Assembly. Two Assemblies required
per machine.
101 See Note NSS Hub (Includes Bearing Cups (Use p/n 1001129381)
102 7010649 1 Seal
103 7010648 1 Cap, Dust
104 7010646 1 Bearing, Cone - Outer
105 7010647 1 Bearing, Cone - Inner
106 7010641 1 Nut, Slotted
107 7019697 1 Washer
108 7010642 1 Pin, Cotter 2 x 3/16
1001130486 Ref TIRE AND WHEEL INSTALLATION A
Ref Note: Must replace Tire and Wheel Assy’s in pairs per axle.
201 0630580 22 Bolt, Wheel
202 1001127628 2 Tire and Wheel Assembly (Rear) (Not Shown)
203 1001129621 2 Tire and Wheel Assembly (Front)
