SECTION 8 - DECALS
114
6RS/10RS/1932RS/3248RS
3121274
FIGURE 8-1. DECAL INSTALLATION (ANSI SPEC)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
Decals Installation
1001147421
Ref
JLG Decals (1932RS)
A
1001133555
Ref
JLG Decals (3248RS)
B
Ref
China Assembled Machines:
1001132946
Ref
ANSI Decals
J
1001130044
Ref
Optional Decals
Ref
USA Assembled Machines:
1001159009
Ref
ANSI Decals
B
1001159008
Ref
ANSI Decals 1932RS Decals
B
1001159008
Ref
ANSI Decals 3248RS Decals
B
1
0860520
1
Box, Manual Storage
2
1001131270
1
Decal - Patent
3
1701504
1
Decal - Hydraulic Oil
4
1701509
1
Decal - Manual Reference
5
Ref
Decal - JLG Options:
5
1702773
3
5in/12.7cm Height
5
1705754
3
3.5in/9cm Height
6
1703177
2
Decal - JLG
7
1703813
2
Decal - Warning Battery Vent
8
1703819
4
Decal - Directional Arrow
9
1703822
1
Decal - Manual Descent
10
1704016
1
Decal - Forklift
11
1704277
3
Decal - Attach Lanyard Here
12
1704412
1
Decal - Hydraulic Oil
13
Ref
Decal - Max Tire Load Options:
13
1705647
4
Decal - Max Tire Load 1932RS
13
1706310
4
Decal - Max Tire Load 3248RS (1835LBS/832KG) (Prior to
SN 0200228445, Prior to SN B200016324)
13
1706311
4
Decal - Max Tire Load 3248RS (2070LBS/939KG) (SN
0200228445 to Present, SN B200016324 to Present)
14
1705679
1
Decal - Inspection
15
1705686
1
Decal - Legend
16
1705694
4
Decal - Crushing Hazard
17
1705695
4
Decal - Danger Electrocution
19
2080040
4
Fastener
20
2080057
4
Fastener
21
See Note
1
Nameplate, Serial Number (Note: Not available for purchase)
22
4110226
4
Decal - Lift Point/Tie Down (Prior to SN B200016324, Prior to
SN 0200228445)
22
1001162864
4
Decal - Lift Point/Tie Down (SN B200016324 to Present, SN
0200228445 to Present)
23
1001132359
1
Decal - Control Box Location
24
Ref
Decal - Capacity Options:
24
1705699
3
Decal - Capacity 1932RS
24
1001132364
3
Decal - Capacity 3248RS
25
1001132376
1
Decal - Danger/Warning
26
Ref
Decal - Model Designation Options:
26
1001134278
2
Decal - Model Designation 1932RS
26
1001132557
2
Decal - Model Designation 3248RS
28
Ref
Decal - Safety Prop Options:
