SECTION 4 - PLATFORM
3121274
6RS/10RS/1932RS/3248RS
77
FIGURE 4-9. PLATFORM CONSOLE BOX ASSEMBLY
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
CONSOLE BOX ASSEMBLY
1001128685
Ref
ANSI, ANSI Export and CSA Specs
G
1001146985
Ref
ANSI Export and CE Specs
B
1
0140030
1
Alarm
2
0700835
1
Bolt M8 x 180
3
0760606
2
Bolt M6 x 12
4
1600402
NLA
Drive/Steer Controller Assembly (Use p/n 1001134438) (See
DRIVE/STEER CONTROLLER ASSEMBLY for Breakdown)
5
1703819
1
Decal - Direction Arrow
7
2920026
AR
Lamp, Indicator (Red)
8
2920028
1
Lamp, Indicator (Yellow)
9
3290405
4
Nut M4
10
3290605
2
Nut M6
11
3290805
1
Nut M8
12
4031509
4
Screw M4 x 25
13
4060906
1
Guard, Switch
14
4360274
1
Switch, Push Button
15
4360345
1
Switch, Toggle
16
4360475
1
Switch, Emergency Stop
16
7020175
1
Cap
16
7020176
1
Block, Contact
17
4811900
2
Washer M8
18
Ref
Plate, Inside Console Options:
18
1001128686
1
ANSI, ANSI Export and CSA Specs (With 2 Indicator Lamps)
18
1001146983
1
ANSI Export and CE Specs (With 3 Indicator Lamps)
19
1001128687
1
Plate, Outside Console
21
1001132358
1
Decal - Steer
22
1001132361
1
Decal - Horn
23
Ref
Decal - Light Function Options:
23
1001132362
1
ANSI, ANSI Export and CSA Specs (With 2 Indicator Lamps)
23
1001146984
1
ANSI Export and CE Specs (With 3 Indicator Lamps - Not
Shown)
24
4711700
2
Washer 7/16
25
4060803
5.25
in/13.5cm
Flex Trim
26
2920094
AR
Bulb, Light
27
4420076
1
ft/30.5cm
Tape
28
3423278
1
Pin with Lanyard
Ref
CONSOLE BOX INSTALLATION
1001131059
Ref
ANSI, ANSI Export and CSA Specs
B
1001143051
Ref
ANSI Export and CE Specs
B
102
Ref
Console Box Assembly Options (Includes Items 1-28):
102
1001128685
1
ANSI, ANSI Export and CSA Specs
102
1001146985
1
ANSI Export and CE Specs
