Page 25
SECTION 1 - FRAME
3121274
6RS/10RS/1932RS/3248RS
25
FIGURE 1-6. COVERS (FRAME MOUNTED) AND LADDER INSTALLATIONS
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001133275
Ref
FRAME COVERS INSTALLATION (6RS/1932RS)
D
1
0760612
4
Bolt M6 x 25
3
3290605
4
Nut M6
5
4811702
8
Washer M6
9
1001133143
1
Cover, Rear
1001130490
Ref
FRAME COVERS INSTALLATION (10RS/3248RS)
E
101
0760610
4
Bolt M6 x 20
102
0760612
2
Bolt M6 x 25
103
4811702
12
Washer M6
104
3290605
6
Nut M6
109
1001130400
1
Cover, Rear
110
1001130474
1
Cover, Frame
Ref
LADDER INSTALLATION (6RS/1932RS)
1001135050
Ref
All Specs except CE Spec
C
1001145913
Ref
CE Spec Only
B
201
0761015
4
Bolt M10 x 35
202
3291005
4
Nut M10
203
4812002
AR
Washer M10
205
Ref
Ladder Options:
205
1001134517
1
All Specs except CE Spec
205
1001145914
1
CE Spec Only
Ref
LADDER INSTALLATION (10RS/3248RS)
1001130964
Ref
All Specs except CE Spec
B
1001142910
Ref
CE Spec Only
B
301
0761014
4
Bolt M10 x 30
302
3291005
4
Nut M10
303
4812000
AR
Washer M10
304
Ref
Ladder Options:
304
1001130532
1
All Specs except CE Spec
304
1001142911
1
CE Spec Only
305
1001151845
1
Decal - Shipping/installation Instructions (Not Shown)
