3120850 3-9
SECTION 3 MAST
S
E
C
T
I
O
N
3
M
A
S
T
1260325 CHAIN ASSEMBLY - #444 Ref. 1/B
201 0561149 Block, Chain Attach 1
202 1260298 Chain 131in/
1.68m
203 3422346 Pin 2
204 0561151 Block, Chain Anchor 2
205 4300111 Stud 3/8”-16NC x 3 1/2” 2
206 0100062 Compound, Locking (Not Shown) A/R
207 3422355 Pin, Grooved 2
208 3537920 Plate 1
209 3422338 Pin, Chain Attach 2
210 4711500 Flatwasher 5/16” (Narrow) 2
211 3450304 Pin, Cotter 3/32” x 1” 2
0270113 MAST SHIELD ASSEMBLY Ref. A
301 3311401 Nut 1/4”-20NC 4
302 4711400 Flatwasher 1/4” (Narrow) 8
303 0641408 Bolt 1/4”-20NC x 1” 4
304 4060993 Shield, Mast Chain/Cable 1
FIGURE 3-2. MAST ASSEMBLY - 15VP (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
