JLG 20VP (3120850) Parts Manual User Manual
Page 28
2-8
3120850
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
28
Supply Locally
Cover, Weatherproof
1
29
0721005
Screw, Machine #10-24NC x 5/8”
2
30
4761000
Lockwasher #10
2
31
3311001
Nut #10-24NC
2
32
4460023
Connector, Strain Relief
1
33
Clamp, Cable Options:
A/R
1320227
Prior to S/N 01966
7
1320043
S/N 01966 to Present
4
34
Hardware Options:
A/R
1020008
Button, Nylon (Prior to S/N 01966)
7
1380132
Clip, Gripper (S/N 01966 to Present)
4
35
4460549
Plug, Electrical (Prior to S/N 02970)
1
36
0960407
Bushing (Prior to S/N 02535)
1
37
4751000
Flatwasher #10 Wide
A/R
38
3300047
Nut, Conduit
1
39
Carrier Options:
A/R
Not Required
10VP & 20VP
0
1180344
15VP
1
40
Plate, Spacer Options:
A/R
Not Required
10VP & 20VP
0
3539617
15VP
2
41
0641409
Bolt 1/4”-20NC x 1”
A/R
42
0641416
Bolt 1/4”-20NC x 2”
A/R
43
0641414
Bolt 1/4”-20NC x 1 3/4”
A/R
44
3760170
Ring, Split
1
45
0100048
Compound, Silicone #661 (Not Shown)
A/R
46
3570737
Bracket, Protector
1
47
Hardware Options:
4
4750800
Flatwasher #8 Wide (Prior to S/N 02535)
3820024
Pop Rivet (S/N 02535 to Present)
48
4760800
Lockwasher #8 (Prior to S/N 02535)
4
49
3310801
Nut #8-32NC (Prior to S/N 02535)
4
50
3910806
Screw #8-32NC x 3/8” (Prior to S/N 02535)
4
51
4740120
Washer, Nylon (S/N 03629 to Present)
4
2901542*
Controller Mounting Kit (Includes Items with * asterisk)
1
FIGURE 2-2. PLATFORM CONTROLS AND CABLES INSTALLATIONS (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
