7-6 3120850
SECTION 7 ELECTRICAL
S
E
C
T
I
O
N
7
E
L
E
C
T
R
I
C
A
L
FIGURE 7-2. HARNESS AND CABLES INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
4932960 ELECTRICAL DIAGRAM - STANDARD Ref. A
1 1060620 Cable, Battery - 21” 2
2 1060619 Cable, Battery - 24” 1
3 1060618 Cable, Battery - 40” 1
4 4921966 Harness - Ground Control 1 3
3990010 Diode 2
4A 4460646 Receptacle - 5 Pin 1
4460647 Shell, Receptacle 2
4B 4460320 Connector, Female - 2 Position 1
4460268 Socket 2
5 4921965 Harness, Valve & Limit Switch 1 3
3990010 Diode 5
5A 4460681 Receptacle - 15 Pin 1
4460643 Shell, Receptacle 1
4460684 Socket 8
5B 4460424 Connector, Male - 2 Position 2
4460267 Pin 2
4460268 Socket 2
5C 2400006 Fuse - 5 Amp 1
4460044 Fuseholder 1
6 4921963 Harness, Right Motor 1 1
6A 4460644 Receptacle - 5 Pin 1
4460645 Pin 2
6B 4460648 Receptacle - 2 Position 1
6C 4460320 Connector, Female - 2 Position 1
4460267 Pin 1
4460268 Socket 2
7 4921964 Harness, Left Motor 1 1
7A 4460644 Receptacle - 5 Pin 1
4460645 Pin 2
7B 4460648 Receptacle - 2 Position 1
7C 4460320 Connector, Female - 2 Position 1
4460267 Pin 1
4460268 Socket 2
8 4921969 Harness - Emergency Stop (Not Shown - Located
inside Ground Control Box) 1 1
9 4921968 Harness, Main Contactor 1 1
3990010 Diode - 6 Amp 2
10 4921967 Harness, Key Switch Power 1 1
10A 2400006 Fuse - 5 Amp 1
4460044 Fuseholder 1
