JLG 20VP (3120850) Parts Manual User Manual
Page 10
1-4
3120850
SECTION 1 BASE
S
E
C
T
I
O
N
1
B
A
S
E
23
Options:
A/R
2860026
Key, Wheel (Prior to S/N 02363)
2
3311505
Locking Nut 5/16”-18NC (S/N 02369 to S/N 03094)
6
24
Options:
A/R
4751000
Flatwasher #10 Wide (Prior to S/N 01703)
2
4740430
Flatwasher, Fender (S/N 01703 to Present)
2
25
3570172
Cover, Motor
1
26
Counterweight Weldment Options:
A/R
Not Required
10VP
0
4845260
15VP
2
4845261
20VP
2
27
0641408
Bolt 1/4”-20NC x 1”
A/R
28
3311405
Locknut 1/4”-20NC
A/R
29
Counterweight Bracket Options:
A/R
Not Required
10VP & 20VP
0
0902256
15VP (Standard Machines)
2
30
Counterweight Weldment Options:
A/R
Not Required
10VP & 15VP
0
4845377
20VP
1
31
0641810
Bolt 1/2”-13NC x 1 1/4”
A/R
32
3311805
Locknut 1/2”-13NC
A/R
33
4751800
Flatwasher 1/2”
A/R
34
2820085
Block, Insulated
2
35
3910620
Screw #6-32NC x (S/N 03094 to Present)
4
36
3310601
Nut #6-32NC (S/N 03094 to Present)
8
37
4750600
Flatwasher #6 (S/N 03094 to Present)
4
38
4711600
Flatwasher 3/8” (S/N 03609 to Present)
8
MAST SUPPORT INSTALLATION OPTIONS:
Ref.
0256197
Prior to S/N 02289
Ref.
4/C
0258582
S/N 02289 to Present
Ref.
1/A
101
Channel, Lift Cylinder Mounting Options:
1
4845478
Prior to S/N 02289
4845804
S/N 02289 to Present
102
0880124
Brace, Mast
2
103
0641609
Bolt 3/8”-16NC x 1 1/8”
11
104
4751600
Flatwasher 3/8” Wide
24
105
3311605
Locknut 3/8”-16NC
12
106
2420140
Gauge, Level
1
107
0641505
Bolt 5/16”-18NC x 5/8”
1
108
4711500
Flatwasher 5/16” Narrow
1
109
0641612
Bolt 3/8”-16NC x 1 1/2”
1
110
1320041
Clamp
1
111
0641404
Bolt 1/4”-20NC x 1/2”
1
112
4711400
Flatwasher 1/4” Narrow
2
113
3311401
Nut 1/4”-20NC
1
114
0100011
Compound, Locking (Not Shown)
A/R
FIGURE 1-1. BASE ASSEMBLY (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
