FIGURE 2-3. BATTERY CHARGER ASSEMBLIES (EUROPE AND AUSTRALIAN)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
BATTERY CHARGER ASSEMBLIES Ref.
Note: Battery Charger Serial Number Nameplate located on
front of charger. To decode built date, look at first line for
for Charger Spec and Date Code.
Example: BA515 (Spec) 9631 (Date Code). First and second
digits in the Date Code indicates year. Third and fourth dig-
its indicate the week of manufacture.
0400166 BATTERY CHARGER ASSEMBLY - 240 VOLT/50HZ
(EUROPEAN MACHINES EXCEPT UK) (BA1028
CHARGER SPEC) Ref. A
0400167 BATTERY CHARGER ASSEMBLY - 250 VOLT/50HZ
(AUSTRALIAN MACHINES) (BA1029 CHARGER SPEC) Ref. B
1 7018551 Transformer 1
2 Card, Circuit Options: 1
7018562 European Machines (Charger p/n 0400166)
7018553 Australian Machines (Charger p/n 0400167)
3 7018554 Shunt Assembly 1
4 Relay, Interlock Options: 1
7018563 European Machines (Charger p/n 0400166)
7018535 Australian Machines (Charger p/n 0400167)
5 7018555 SCR Rectifier 2
6 7018537 Varistor 1
7 AC Cord Assembly Options: 1
7011455 European Machines (Charger p/n 0400166)
Not Required Australian Machines (Charger p/n 0400167)
8 Connector, Strain Relief - 90° Options: 1
7018556 European Machines (Charger p/n 0400166)
Not Required Australian Machines (Charger p/n 0400167)
9 7018567 DC Harness Assembly 1
9A 4460424 Connector, Male - 2 Position 1
4460267 Pin, Male 2
9B 7011528 Connector, Strain Relief 1
10 Breaker, Circuit - AC Options: 1
7018557 European Machines (Charger p/n 0400166)
7018536 Australian Machines (Charger p/n 0400167)
11 7011509 Breaker, Circuit - DC 1
12 Socket, AC Options: 1
Not Required European Machines (Charger p/n 0400166)
7011667 Australian Machines (Charger p/n 0400167)
