3120850 2-19
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
.
FIGURE 2-7. OPTION INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0256541 HOURMETER INSTALLATION - OPTION Ref. B
1 2420165 Gauge, Hourmeter 1
2 0902296 Bracket 1
3 3910608 Screw, Machine #6-32NC x 1/2” 4
4 3310601 Nut #6-32NC 4
5 Not Used
6 4760600 Lockwasher #6 4
TILT INDICATOR INSTALLATION - OPTIONS: Ref.
0256545 Prior to S/N 02996 Ref. 3
0270068 S/N 02996 to Present Ref. 1
101 Switch, Tilt Options: 1
4360435 Prior to S/N 02996
4360465 S/N 02996 to Present
102 4300106 Stud, Grooved 4
0256540 ALARM INSTALLATION - OPTION Ref. C
201 0140033 Alarm (Remove Ground Strap Before Installing) 1
202 0641406 Bolt 1/4”-20NC x 3/4” 2
203 3311405 Locknut 1/4”-20NC 4
204 4711400 Flatwasher 1/4” (Narrow) 4
205 3911410 Screw, Machine 1/4”-20NC x 5/8” 2
206 0902356 Bracket 1
0256539 HORN INSTALLATION - OPTION Ref. D
301 0140022 Horn 1
302 0641507 Bolt 5/16”-18NC x 7/8” (Prior to S/N 02938) 1
303 3311505 Locknut 5/16”-18NC (Prior to S/N 02938) 1
304 4711500 Flatwasher 5/16” (Narrow) (Prior to S/N 02938) 2
305 3740069 Relay 1
306 0902354 Bracket (With Horn Only) (Prior to S/N 02938) 1
307 3539964 Spacer (Prior to S/N 02938) 1
308 3911416 Screw, Machine 1/4”-20NC x 1” (Prior to S/N 02938) 2
309 3311405 Locknut 1/4”-20NC (Prior to S/N 02938) 2
310 4711400 Flatwasher 1/4” (Narrow) (Prior to S/N 02938) 2
311 3911010 Screw, Machine #10-24NC x 5/8” 1
312 3311001 Nut #10-24NC 1
313 4751000 Flatwasher #10 2
314 4761000 Lockwasher #10 1
