3120850 2-17
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
.
FIGURE 2-6. CONTROL BOX ASSEMBLY
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
CONTROL BOX ASSEMBLIES Ref.
1600267 PRIOR TO S/N 02996 Ref. A
1600304 S/N 02996 TO PRESENT Ref. A
1 No Longer
Available
Printed Circuit Board (was p/n 7020147 - Must Purchase
Complete Control Box) 1
2 Joystick Options: 1
7020141 Prior to S/N 02996
7023201 S/N 02996 to Present
3 7020144 Emergency Stop Actuator 1
4 7020145 Contact Block, Emergency Stop 1
5 7020143 Knob Potentiometer 1
6 7020142 Potentiometer 1
7 Membrane Keyboard Pad Options: 1
7020146 Prior to S/N 02996
7023202 S/N 02996 to Present
8 7020139 Joystick Box W/Gasket 1
9 Connector, 12 Position Options: 1
Not Available Prior to S/N 02996
7026038 S/N 02996 to Present
7026039 Pin 12
