3120850 2-7
SECTION 2 CONTROLS
S
E
C
T
I
O
N
2
C
O
N
T
R
O
L
S
.
FIGURE 2-2. PLATFORM CONTROLS AND CABLES INSTALLATIONS
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
PLATFORM CONTROLS AND CABLES INSTALLATIONS Ref.
0257624 10 VP Ref. 11
0257610 15 VP Ref. 10
0257601 20 VP Ref. 12
1 3570680* Plate, Control Mounting 1
1A Pad, Rubber Options: A/R
7020075 RH Side Pad 2
7020076 LH Side Pad 2
2 Not Used
3 Platform Console Box Assembly Options (See Figure 2-6
for Breakdown): 1
1600267 Console Box Assembly (Prior to S/N 02996)
1600304 Console Box Assembly (S/N 02996 to Present)
4 1060663 Cable, Electrical A/R
10 VP 13.2ft/4m
15 VP 18.7ft/5.7m
20 VP 22.3ft/6.8m
5 Platform Harness Assembly Options: (See Section 7 for
Breakdown) 1
4922027 10 VP (Prior to S/N 02445)
4922201 10 VP(S/N 02445 to Present)
4922028 15 VP (Prior to S/N 02445)
4922202 15 VP(S/N 02445 to Present)
4922029 20 VP (Prior to S/N 02445)
4922203 20 VP(S/N 02445 to Present)
6 3422657* Pin, Quick Release 1
7 1060380* Cable, Lanyard 2
8 1320043* Clamp, Cable 1
9 3310801* Nut #8-32NC A/R
10 4750800* Flatwasher #8 Wide A/R
11 3300416* Nut, Acorn #8-32NC 4
12 0100035 Compound, Locking (Not Shown) A/R
13 4160130 Spring, Extension 1
14 3311605 Locknut 3/8”-16NC 1
15 1320149 Clamp 3
16 0641412 Bolt 1/4”-20NC x 1 1/2” 3
17 0100019 Compound, Locking (Not Shown) A/R
18 3311405 Locknut 1/4”-20NC 7
19 3580231 Pulley, Sheave A/R
20 3900200 Screw, Shoulder 5/16”-18NC x 1 1/4” A/R
21 4751500 Flatwasher 5/16” Wide A/R
22 0641406 Bolt 1/4”-20NC x 3/4” 4
23 4711400 Flatwasher 1/4” Narrow A/R
24 4460566 Connector, Strain Relief - 90 ° 1
25 3380441 Panel, Control 1
26 0860946 Box, Electrical 1
27 Supply Locally Receptacle, Electrical 1
