SECTION 9
RECOMMENDED SERVICE PARTS STOCK
10VP/15VP/20VP
The following list will service fleets of machines (built to current production per date on the front cover) with
emergency repair parts which can be installed in the field. Parts from the list should be replaced when inven-
tory is depleted to keep service parts stock supplied. For further information, contact your JLG dealer or the
JLG Industries Parts Department.
JLG PART
NUMBER
DESCRIPTION
QTY PER FLEET
1-10
10-20
20 OR MORE
STANDARD PARTS
7014117
Switch, Micro (Figure 1-2)
1
1
1
3740130
Relay 100-Amp (Figure 2-1)
1
1
1
4360314
Switch, Toggle (Figure 2-1)
1
1
1
3740069
Relay, Power 24 VDC (Figure 2-1)
1
1
1
7020078
Switch, Push-Turn (Figure 2-1)
1
1
1
4360471
Switch, Key (Figure 2-1)
1
1
1
7020174
Key, Replacement (Figure 2-1)
1
1
1
1600304
Control Box Assembly (Figure 2-2)
1
1
1
7011509
Breaker, Circuit - DC (Figures 2-3 & 2-4)
1
1
1
7018557
Breaker, Circuit - AC (Figures 2-3 & 2-4)
1
1
1
7013723
Filter - Hydraulic (Figure 2-5)
4
8
12
7016714
Breather (Figure 2-5)
1
2
3
3990010
Diode (Figure 7-2)
2
2
2
2400006
Fuse - 5 Amp (Figure 7-2)
2
2
2
VARIABLE PARTS
4360456
Switch, Limit (Figure 1-4)
1
1
1
7018563
Relay (European Spec) (Figure 2-3)
1
1
1
7018535
Relay (Australian Spec) (Figure 2-3)
1
1
1
7018564
Relay (UK Spec) (Figure 2-4)
1
1
1
4360435
Switch, Tilt (Figure 2-5)
1
1
1
4360437
Switch, Limit (Figure 3-1, 3-2 & 3-3)
1
1
1
