JLG 20VP (3120850) Parts Manual User Manual
Page 47
3120850
3-7
SECTION 3 MAST
S
E
C
T
I
O
N
3
M
A
S
T
.
FIGURE 3-2. MAST ASSEMBLY - 15VP
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
0801115
MAST ASSEMBLY - 15VP
Ref.
4/B
1
1271342
Channel, Mast #1
1
2
1271343
Channel, Mast #2
1
3
1271345
Channel, Mast #3
1
4
1271357
Channel, Mast #4
1
5
Not Used
6
0362377
Bar, Sheave Pin Support
4
7
1260324
Chain Assembly - #466 (See Items 101-107 for Breakdown)
2
8
1260325
Chain Assembly - #444 (See Items 201-211 for Breakdown)
1
9
Not Used
10
3580227
Chain, Sheave - #466
2
11
3580226
Chain, Sheave - #444
2
12
0561152
Block, Anchor
1
13
3537932
Plate, Chain Adjustment
1
14
3422341
Pin
1
15
3422361
Pin, Sheave
2
16
4070860
Shim 3/4”
15
17
4845544
Chain Attach Weldment (Bottom)
1
18
0901993
Bracket, Chain Attach (Bottom)
1
19
0641410
Bolt 1/4”-20NC x 1 1/4”
10
20
0902047
Bracket, Sequence Cable
2
21
Not Used
22
4566487
Tube, Spacer
2
23
Not Used
24
Not Used
25
Pad, Slide Options:
10
3340704
Prior to S/N 02816
3340845
S/N 02816 to Present
26
4070861
Shim 1/32”
3
27
4070862
Shim 1/64”
10
28
3900210
Screw, Button Head 5/16”-18NC x 3/4”
4
29
4761600
Lockwasher 3/8”
2
30
1683554
Lift Cylinder Assembly (See Section 5 for Breakdown)
1
31
3900192
Screw, 3/8”-16NC x 1/2”
8
32
3422339
Pin
1
33
3311405
Locknut 1/4”-20NC
2
34
4740414
Washer, Cup
2
35
4160124
Spring
2
36
Sheave, Cable
2
3580228
Prior to S/N 02947
3580269
S/N 02947 to Present
37
0902042
Bracket, Pulley
2
38
3900187
Screw, Shoulder
2
39
4711400
Flatwasher 1/4” (Narrow)
60
40
3900191
Screw #10-24NC x 3/4”
6
41
4761000
Lockwasher #10
10
42
0641406
Bolt 1/4”-20NC x 3/4”
36
