SECTION 2 - TURNTABLE
56 M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M 3121128
ITEM PART NUMBER QTY DESCRIPTION REV
19 0641413 AR Bolt 1/4in-20NC x 1-5/8in
19 0641426 AR Bolt 1/4in-20NC x 3-1/4in
21 Ref Jib Valve Assembly Options:
21 Not Required 0 Jib Valve Assembly (E/M450A & E/M400A Models)
21 4641102 1 Jib Valve Assembly (E/M450AJ Models) (use p/n 1001097775)
(Prior to SN 0300129142)
21 1001097775 1 Jib Valve Assembly (E/M450AJ Models) (Shown) (SN
0300129142 through 0300189898)
21 4641119 1 Jib Valve Assembly (E/M400AJP Models) (use p/n
1001097505) (Prior to SN 0300129142)
21 1001097505 1 Jib Valve Assembly (E/M400AJP Models) (SN 0300129142
through 0300189901)
21A 7017452 1 Cartridge without Coils
21A 7017402 1 Seal Kit - 7017452 Cartridge
21A 7021609 2 Coil
21B Ref Cartridge, Relief Valve Options:
21B 70002807 1 Port RV1(was p/n 7017460)
21B 70002808 1 Port RV2 - E/M400AJP Models Only (was p/ns 7021623 &
7017460)
21B 7021653 AR Seal Kit - 70002807 & 70002808 Cartridges
22 0100011 AR Compound, Locking
Ref RELEVELING VALVE ASSEMBLIES
Ref Note: Refer to Item 2 for Usage.
4641029 Ref Releveling Valve
4641394 Ref Releveling Valve
1001097777 Ref Releveling Valve
101 7017466 1 Cartridge
101 2900708 1 Seal Kit - 7017466 Cartridge
102 7012959 1 Knob
103 Ref Cartridge Options:
103 7012981 Cartridge - 4641029 Valve
103 7012998 1 Seal Kit - 7012981 Cartridge
103 7024891 Cartridge - 4641394 & 1001097777 Valves
103 7012953 1 Seal Kit - 7024891 Cartridge
0259064 Ref ALARM INSTALLATIONS 1
201 0140031 1 Alarm, Motion (Remove ground strap before installation)
201 3311405 2 Locknut 1/4in-20NC
201 4711400 4 Flatwasher 1/4in Narrow
201 0641408 2 Bolt 1/4in-20NC
201 4460685 2 Terminal, Stud Mounted Tab
