SECTION 5 - CYLINDER
3121128
M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M
189
FIGURE 5-12. MASTER CYLINDER ASSEMBLY (E/M450AJ & E/M400AJP) (Prior to SN 0300163453)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1683923
Ref
MASTER CYLINDER ASSEMBLIES
F
Ref
Note: Original Equipment components may have been
replaced with Service Replacement components part. Identify
p/n stamped on cylinder before ordering parts.
1
0100011
AR
Compound, Locking
2
0100038
AR
Primer, Locking
3
3931016
3
Bolt Socket Head #10-24NC x 1in
4
0962185
1
Tapered Bushing
5
0961951
4
Bushing, Garmax
6
3480259
1
Piston
7
3760368
1
Washer, Ring
8
1683925
1
Head
9
1683756
1
Barrel
10
1683772
Rod
12
2901898
2
Ring, Lock
13
2901898
1
Ring, Wear
14
2901898
2
Ring, Back-Up
15
2901898
1
O-Ring
16
2901898
1
O-Ring
17
2901898
1
Wiper
18
2901898
1
Seal
19
2901898
1
Ring, Back-Up
20
2901898
2
Seal
21
3931516
8
Bolt Socket Head 5/16in-18NC x 1in
100
2901898
1
Seal Kit (Includes Items 12-20)
