SECTION 5 - CYLINDER
3121128
M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M
165
FIGURE 5-4. PLATFORM LEVEL CYLINDER ASSEMBLY (E/M450A & E/M400A) (E/M400A SN
0300165128 through 0300189901; E/M450A SN 0300165128 through 0300189898)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
1001140598
Ref
PLATFORM LEVEL CYLINDER ASSEMBLY
A
Ref
Note: Original Equipment components may have been
replaced with Service Replacement components part. Identify
p/n stamped on cylinder before ordering parts.
1
70004146
1
Barrel
2
70004147
1
Rod
5
70000739
1
Head
6
70004141
1
Piston
7
See Note
4
Plug (Note: Not available for purchase)
9
70004131
2
Ring, Wear
10
70004131
1
Seal
11
70023094
1
O-RING
12
70004142
1
Retainer
13
70004143
1
Spacer
14
70004131
1
O-Ring
15
70004131
1
Ring, Back-up
16
70004131
1
Wiper
17
70004131
1
Seal
18
70004131
1
O-Ring
19
70000740
1
O-Ring
20
0962356
4
BUSHING
21
4640509
1
Cartridge, Counterbalance Valve
21
2900792
1
Seal Kit -4640509 Valve
22
70024262
2
Plug
23
See Note
2
Plug (Note: Not available for purchase)
26
4640932
1
Cartridge, Counterbalance Valve
26
7011112
1
Seal Kit - 4640832 Valve
50
70004131
1
Seal Kit (Includes Items 9-11 & 14-18)
