SECTION 3 - BOOM
104
M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M
3121128
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
135
3311805
1
Locknut 1/2in-13NC
136
0641607
1
Bolt 3/8in-16NC x 7/8in
137
3422792
1
Pin
138
Ref
Jib Assembly Options (Includes Items 1-27):
138
0259440
1
Jib Assembly (E/M450AJ) (Prior to SN 0300061430)
138
0270400
1
Jib Assembly (E/M450AJ) (SN 0300061430 through
0300189898)
139
0641809
1
Bolt 1/2in-13NC x 1-1/8in
144
0100011
AR
Compound, Locking
Ref
PLATFORM ROTATOR AND SUPPORT INSTALLATION (FRONT
ENTRY PLATFORM)
0259439
Ref
Platform Rotator and Support Installation (Front Entry
Platform) (E/M450AJ Models)
E
201
4846322
1
Weldment, Support
202
0681608
6
Bolt 3/8in-16NC x 1in (Grade 8)
203
0100011
AR
Compound, Locking
204
0641407
2
Bolt 1/4in-20NC x 7/8in
205
4740362
4
Washer, Fender
206
3311405
2
Nut 1/4in-20NC
207
0641610
6
Bolt 3/8in-16NC x 1-1/4in
208
4711600
18
Flatwasher
209
3311605
6
Locknut 3/8in-16NC
Ref
PLATFORM ROTATOR AND SUPPORT INSTALLATION (SIDE
ENTRY PLATFORM)
0272976
Ref
Platform Rotator and Support Installation (Side Entry
Platform) (E/M450AJ without Load Sensing)
A
See Note
Ref
Platform Rotator and Support Installation (Side Entry
Platform) (E/M450AJ with Load Sensing) (Note: Refer to JLG
Supplement p/n 3124287 for Components)
301
0100011
AR
Compound, Locking
302
0641610
8
Bolt 3/8in-16NC x 1-1/4in
303
0681608
6
Bolt 3/8in-16NC x 1in (Grade 8)
304
3311605
8
Locknut 3/8in-16NC
305
4711600
16
Flatwasher 3/8in
306
Ref
Weldment, Support Options:
306
4846608
1
Weldment, Support (E/M450AJ without Load Sensing)
306
See Note Above
1
Weldment, Support (E/M450AJ with Load Sensing)
307
4891600
6
Flatwasher 3/8in Hardened
