SECTION 4 - PLATFORM
3121128
M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M
135
FIGURE 4-4. PLATFORM PADDING INSTALLATION (FRONT ENTRY PLATFORM)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
Ref
PLATFORM PADDING INSTALLATION OPTIONS:
0270338
Ref
30in x 48in
B
0271937
Ref
Platform Padding Installation (30in x 60in)
1-A
1
Ref
Bolt Options:
1
0641508
4
30in x 48in Assemblies (Bolt 5/16in-18NC x 1in)
1
0641506
4
30in x 60in Assemblies (Bolt 5/16in-18NC x 3/4in)
2
0641516
2
Bolt 5/16in-18NC x 2in
3
0940094
AR
Padding
4
Ref
Nut Options:
4
3311501
6
30in x 48in Assemblies (Nut 5/16in-18NC)
4
3311505
6
30in x 60in Assemblies (Locknut 5/16in-18NC)
6
4420068
36 ft/11m
Tape, Yellow Adhesive
8
4751500
6
Flatwasher 5/16in (Wide)
9
4761500
6
Lockwasher 5/16in
10
Ref
Bumper Rail Options:
10
4844917
1
30in x 48in Assemblies
10
4845346
1
30in x 60in Assemblies
11
0940091
2
Corner, Padded
12
0940092
2
Corner, Padded
13
0940093
AR
Padding (Bottom)
