SECTION 5 - CYLINDER
172 M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M 3121128
ITEM PART NUMBER QTY DESCRIPTION REV
8 2900770 1 Seal Kit - 4640816 Valve
8 4641386 1 Cartridge, Holding Valve For 1684451, 1684453 & 1684492
Cylinder
8 7011376 1 Seal Kit - 4641386 Valve
9 4640634 1 Cartridge, Holding Valve
9 2900770 1 Seal Kit - 4640634 Valve
10 Ref Plug Options:
10 2220885 2 1683711, 1684024, 1684058, 1684453 & 1684492 Cylinders
10 Not Required 0 1683826, 1683939 & 1684451 Cylinders
11 3900170 1 Setscrew
12 See Note 1 Seal, Piston (Note: Use Items 100A & 100B)
13 See Note 2 Ring, Wear (Note: Use Items 100A & 100B)
14 See Note 1 O-Ring (Note: Use Items 100A & 100B)
15 See Note 3 Ring, Wear (Note: Use Items 100A & 100B)
16 See Note 1 O-Ring (Note: Use Items 100A & 100B)
16 2901805 1 Ring, Back-up (1684024 Cylinder Only)
17 See Note 1 Seal, Rod (Note: Use Items 100A & 100B)
18 See Note 1 Wiper, Rod (Note: Use Items 100A & 100B)
20 0100011 AR Compound, Locking
21 0100035 AR Compound, Locking
22 0100038 AR Primer, Locking
23 Ref Bushing Options:
23 0961726 4 1683711 & 1683826 Cylinders
23 0961950 4 1683939, 1684024, 1684058, 1684551, 1684453 & 1684492
Cylinders
100 Ref Seal Kit Options (Includes Items 12-18):
100A 2901806 1 1683711, 1683826, 1683939, 1684492, 1684451 & 1684058
Cylinders
100B 2901805 1 1684024 & 1684453 Cylinders
