SECTION 4 - PLATFORM
3121128
M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M
133
FIGURE 4-3. PLATFORM COMPONENTS INSTALLATION (FALL ARREST PLATFORM) (OPTIONAL)
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
3510884
Ref
PLATFORM ASSEMBLY (FALL ARREST) (OPTIONAL)
(E/M450A/AJ ONLY)
B
Ref
Note: Replacement Decals Must be Ordered Separately - See
DECAL SECTION.
1
0681822
4
Bolt 1/2in-13NC x 2-3/4in
2
1060919
1
Cable, Fall Arrest
3
1705014
1
Decal - Safety
4
1706385
1
Decal - Drop Bar
5
2410014
1
Gate Weldment
6
3271805
4
Locknut 1/2in-13NC
7
3311605
1
Locknut 3/8in-16NC
8
3510884
1
Platform Weldment (Note: Not available for purchase)
9
3520072
1
Cap-Plug
10
3900054
1
Bolt 1/2in-13NC x 1-3/4in
11
4751800
8
Flatwasher 1/2in (Wide)
12
0962270
2
Bearing, Oilite
Ref
PLATFORM PADDING INSTALLATION (OPTIONAL)
0275698
Ref
Platform Padding Installation 36in x 72in Platform
A
101
0940092
2
Pad, Corner Bumper
102
0940094
AR
Pad, Bumper Options:
102A
Ref
Pad, Bumper 14.875in
102B
Ref
Pad, Bumper 13.750in
102C
Ref
Pad, Bumper 14.500in
102D
Ref
Pad, Bumper 22.000in
103
4420068
AR
Tape, Yellow Safety
104
0940198
1
Kit, Pre-Cut Bumper
