SECTION 1 - FRAME
3121128
M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M
33
ITEM
PART NUMBER
QTY
DESCRIPTION
REV
113
1320136
1
Clamp, Insulated
Ref
DELTA-Q BATTERY CHARGER INSTALLATIONS (E/M400) (SN
0300144567 through 0300189901)
Ref
DELTA-Q BATTERY CHARGER INSTALLATIONS (E/M450) (SN
0300144567 through 0300189898)
1001123054
Ref
Machines with 110V Plug (ANSI, ANSI Export and CSA Specs)
B
1001107780
Ref
Machines with Locally Supplied Plug (ANSI Export Spec)
B
201
0610131
1
Charger LED Assembly
202
0641404
1
Bolt 1/4in-20NC x 1/2in
203
0641405
4
Bolt 1/4in-20NC x 5/8in
204
0641406
2
Bolt 1/4in-20NC x 3/4in
205
0641408
2
Bolt 1/4in-20NC x 1in
207
1320136
1
Clamp, Insulated
208
3311405
9
Locknut 1/4in-20NC
209
3571834
1
Plate, Panel
210
4240033
4
Tie-Strap
213
4711400
16
Flatwasher 1/4in Thin
214
1001103105
1
Battery Charger Assembly (See ELECTRICAL SECTION for
Breakdown)
215
1001107779
1
Plate, Battery Charger Mounting
301
2915230
1
BATTERY CHARGER REPROGRAM CONTROLLER KIT (was
p/n 1600466)
