SECTION 4 - PLATFORM
3121128 M450A/E400A/M400AJPnarrow/E450A/E400AJPnarrow/M400A/E450AJ/M 139
FIGURE 4-6. SOFT-TOUCH INSTALLATION (OPTIONAL)
ITEM PART NUMBER QTY DESCRIPTION REV
Ref SOFT-TOUCH INSTALLATION (OPTIONAL)
0274323 Ref 36in x 72in Platform A
1 0100011 AR Compound, Locking
2 0200048 2 Arm, Switch Activator
3 0630462 8 Bolt, Carriage
4 0641414 8 Bolt 1/4in-20NC x 1-3/4in
5 0721005 4 Screw #10-32NF x 5/8in
6 0940167 Bumper Kit (Includes Corners and Enough Straight Material for
One Platform)
7 1060494 15 ft/4.6m Cable, Control - 12/3
8 1060903 4 Wire Rope and Eyebolt Assembly
9 1702938 1 Decal, Soft Touch Override
10 3311401 8 Nut 1/4in-20NC
11 3311501 8 Nut 5/16in-18NC
12 3575705 2 Plate, Switch Strike
13 4240099 1 Tie, Wire
14 4360057 2 Switch, Limit
15 4360387 1 Switch, Yellow Push Button
16 4420068 1 Tape, Yellow Adhesive
17 4460049 2 Connector, Strain Relief
18 4460234 2 Terminal, Mount Cable Tie
19 4460425 1 Terminal, Strain Relief (Not Shown)
20 4751400 16 Flatwasher 1/4in (Wide)
21 4751500 8 Flatwasher 5/16in (Wide)
22 4751800 8 Flatwasher 1/2in (Wide)
23 4846370 1 Rail, Soft Touch
