Page 25

Operating controls and function
New Brunswick
™
Excella
®
E-24 Shaker
English (EN)
25
6.1.4
Function indicators
4 function indicator lights are located to the right of the LED DISPLAY. They indicate the current
parameter(s) being displayed.
Indicator
Meaning
Description
°C
Interior chamber temperature
• When in SET mode, can be set
between 7
°C and 60
°C
using
the
or
keys
• Indexes at 0.1
°C
increments
unless the
or
key is
pressed for 4 seconds, after
which it indexes more rapidly
RPM
Revolutions per minute
• When in SET mode, use the
or
key to change the speed
• Indexes at 1 RPM increments
unless the
or
key is
pressed for 4 seconds, after
which it indexes more rapidly
HRS
Time remaining in a timed run
• Can be set from 0.1 to 99.9
hours using the
or
keys
• Indexes at 0.1 hour increments
unless the
or
key is
pressed for 4 seconds, after
which it indexes more rapidly
MUTE
Audible alarm mute
• Controlled by the SELECT key
• When activated, the audible
alarm is muted, and remains
so until is is reactivated
• If MUTE is ctivated when the
shaker is turned off, it will
remain active when the unit is
powered on
• Press the SELECT key until the
MUTE indicator illuminates;
press the
or
key to
display ON or OFF as desired,
then press SELECT.
