*UDSK GLVSOD\
With the graph display the results of a maximum of eight channels can be displayed over time
simultaneously. The number of channels and their units are set in the parameter window. Channel
labels are provided to be able to differentiate in the case of later scale assignment (yi), (e.g. Curve 1,
2, etc.). In addition, the y-axis can be limited to the value range of interest (ymax, ymin scale).
The coloration of the graph display can be selected individually, while the line width of the measuring
curve can also be changed.
Proceed as follows:
1. Open the parameter window of the result unit by double clicking on the appropriate
symbol.
2. If required, enter the 0RGXOH QDPH in the ’Description’ text field.
3. Set the 1XPEHU RI FKDQQHOV with the upper arrow buttons.
4. Select the channels with the lower arrow buttons.
5. Enter the
'HVFULSWLRQ , 8QLW (e.g. rpm) and 0LQLPXP and 0D[LPXP value of the Y-scale
for each channel.
6. $FWLYDWH the channel with the control field so that results appear in the result window.
7. Close the parameter window with 2. . The result window appears as a symbol (icon) at
the bottom of the screen.
8. Open the result window by double clicking on the icon. The result window appears in the
normal size with the current scale.
Control input:
Trigger input: you can start data acquisition, time or event-driven, by switching the trigger
input from low to high. The trigger event can be produced by any control unit (push button,
switch, trigger, timer, …). If the trigger input is not in use, data acquisition will start when
measuring begins.
The scale parameters can be individually set depending on the measuring variables and the
number of channels to be displayed:
