ADVANCE ADAPTERS INC. P/N: 716806
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 10
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 04-25-14
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will void
any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend that
you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive dealerships
and parts stores.
KIT CONSISTS OF:
No. Qty Part No. Description
POWER STEERING CONVERSION
JEEP UNIVERSAL
JEEP SAGINAW STEERING INSTRUCTIONS:
Advance Adapters, Inc. has been manufacturing steering conversion parts for installation of the Saginaw steering boxes into Jeep
vehicles for more than twenty years. The parts we furnish are of the highest quality available and we utilize only proven design
components for our kits. Before you consider the conversion, we recommend that you thoroughly read and understand the complete
procedure. Do not take short cuts on steering installations. We recommend that these conversions be installed by a qualified
technician.
Do not overlook any details. Remember that the control of your vehicle depends on the steering gear performance.
Failure of your steering system can result in severe damage and possibly injury.
1. 1 716810 COLUMN BUSHING
2. 4 716812 CLAMP (Tie Rod)
3. 1 716814 CLAMP
4. 1 716817 PITMAN ARM-POWER
5. 1 716823 COLUMN MOUNTING PLATE
6. 2 716824 FRAME ENCLOSURE
7. 1 716829 SHORT TIE ROD
8. 1 716830 LONG TIE ROD
9. 1 716835-BLK *36 TOOTH SPUD SHAFT
10. 1 716838-BLK POWER BOX MOUNTING PLATE
11. 1 716841 Universal Joint (1" DD X 1"DD)
11. 1 716847 7/8" UNIVERSAL/FLAMING RIVER
12. 1 716863 STEERING SHAFT-36" COLLAPSIBLE JOINT
13. 1 723703 3/8" NYLON LOCK NUT
14. 1 723704 WASHER
15. 1 723725 H.H.C.S. 3/8"-16 x 2" BOLT
16. 4 724324 HIGH COLLAR WASHER
17. 4 724347 7/16" x 1-1/2" GRD. 8 / 12 PT. BOLTS
** Kit does not include the Saginaw Steering Box, Steering Hoses or New Tie Rod Ends for Military Replacement.
P/N 716834-30 - Spud shaft .730” dia. x 30T (manual & power) (male side is 1" double D as of 5/24/13)
P/N 716835 - Spud shaft .800” Dia. x 36T (power)(male side is 1" double D as of 4/25/14)
