SHEET METAL SCREW
FLOOR BOARD
1/4"-20 X 1" H.H.C.S.
IF THE STEP DOES NOT FIT FLUSH ON BODY UNDER PANEL,
THEN A REAR SUPPORT BRACKET MUST BE MADE AND
INSTALLED. (MATERIAL SUPPLIED)
1/4"-20 X 1"
1/4"-20 X 1" SLOT HEAD MACH. SCREW
4 PLACES
BODY SEAM
SHEET METAL 3 PLACES
STANDARD INSTALLATION
ALTERNATE INSTALLATION
ADVANCE ADAPTERS INC. P/N: 716870
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 2 OF 2
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 06-15-93
SPRING UP FOLDING STEPS
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will void
any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend that
you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive dealerships
and parts stores.
