Advance Adapters 716870 User Manual
Spring up folding steps

SPECIAL NOTE:
The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will void
any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend that
you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a service
manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive dealerships
and parts stores.
KIT CONSISTS OF:
No.
Qty
Part No.
Description
ADVANCE ADAPTERS INC.
P/N: 716870
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 2
Telephone: (800) 350-2223
Fax: (805) 238-4201
Page Rev. Date:
10-29-96
1.
2
716864
STEEL STRIP
2.
1
716870L-BLK
DRIVER'S SIDE STEP ASSEMBLY
3.
1
716870R-BLK
PASSENGER SIDE STEP ASSEMBLY
BOLT LIST:
1.
10
722514
1/4"-20 NYLON LOCK NUT
2.
10
722518
1/4"-20 x 7/8" PAN HEAD MACH. SCREW
3.
20
722523
1/4" FLAT WASHERS
4.
6
723144
1" LG SHEET METAL SCREWS
*THESE PARTS ARE USED IN STEP ASSEMBLY
FRONT OF VEHICLE
DRILL 9/32" DIA. HOLES
2" APART
(4) 1/4"-10 X 1"
SLOT HD. MACH SCR.
APPROX. 11"
RIDER'S SIDE
(DRIVER'S SIDE TO BE OPPOSITE OF SHOWN)
SPRING UP FOLDING STEPS
ROCKER DOUBLE SEAM
