Spal 16" puller fan kit, Kit consists of

KIT CONSISTS OF:
No.
Qty
Part No.
Description
ADVANCE ADAPTERS INC.
P/N: 716670
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 4
Telephone: (800) 350-2223
Fax: (805) 238-4201
Page Rev. Date:
08-09-13
SPECIAL NOTE:
The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
1.
1
716675
16" SPAL PULLER FAN
2.
1
716677
16" MOUNTING BRKT
3.
1
716678
WIRE HARNESS
SPAL 16" PULLER FAN KIT
Note: Due to moving an extreme amount of airflow, these fans are quite loud!
SPAL Fans - Technical Specifications
AA#
DESCRIPTION
HEIGHT (IN)
DEPTH (IN)
WIDTH (IN)
AIRFLOW (CFM)
716675
16" High Performance-Puller- Straight Blade
16.3
3.39
15.75
2360
716676
16" High Performance –Pusher- Straight Blade
16.3
3.39
15.75
2360
