KIT CONSISTS OF:
No. Qty Part No. Description
ADVANCE ADAPTERS INC. P/N: 50-9704
P.O. Box 247, 4320 Aerotech Center Way New Item: (11/93)
Paso Robles, CA 93447 PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 06-18-08
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
1. 1 51-9702 CASTING (SM420 Jeep)
2. 1 52-9704 SPUD SHAFT - 23 SPLINE
3. 1 716453 SNAP RING
4. 1 716454 SET COLLAR
5. 1 716508 GASKET
6. 1 716517 GASKET (Dana 300)
7. 8 723701 3/8"-16 NUTS
8. 14 723704 3/8" LOCKWASHER PLT.
9. 8 723711 3/8"-16 x 2" STUD BOLT
10. 1 JP001 JEEP INSTRUCTION MANUAL
INSTALLATION NOTES:
This kit should be used when replacing the Jeep AX15 5 speed transmission. The spud shaft should protrude approximately
7/16" beyond the face of the adapter housing. In order for this kit to be used with the AX15 transfer case, you will need
to change the input gear of the transfer case to the short design.
GM TRUCK 4SP MODEL SM420 TO
JEEP NP231 T/C LONG STICKOUT
