ADVANCE ADAPTERS INC. P/N: 50-6202
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711062-16
Paso Robles, CA 93447 PAGE 3 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 04-04-13
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components
will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly
recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We
recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are
normally available at automotive dealerships and parts stores.
FORD NP435 4SPD TRANSMISSION
TO TOYOTA L/C 4SPD TRANSFER CASE
CAUTION:
When installing a new transmission main shaft into the new process case you must make sure
the input shaft is properly pre-loaded for proper bearing and gear clearances. We have
experienced gear seizure in the 3rd area of the transmission shaft due to the improper
clearance from the front input shaft. The 3rd gear to input shaft clearance must be .010"
to .015" in order to avoid severe damages. If this clearance is not obtained, you will find
the input shaft dragging on 3rd gear and creating excessive heat that will cause gear seizure.
Refer to ford service manual for specific instructions on transmission assembly procedures.
