Advance Adapters 50-6202 User Manual
Optional items

OPTIONAL ITEMS:
Qty
Part No.
Description
ADVANCE ADAPTERS INC.
P/N: 50-6202
P.O. Box 247, 4320 Aerotech Center Way
Old Part No: 711062-16
Paso Robles, CA 93447
PAGE 1 OF 3
Telephone: (800) 350-2223
Fax: (805) 238-4201
Page Rev. Date:
04-04-13
KIT CONSISTS OF:
No.
Qty
Part No.
Description
SPECIAL NOTE:
The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that
a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at
automotive dealerships and parts stores.
1
716004
REAR MOUNT
1
716003
CROSSMEMBER
FORD NP435 4SPD TRANSMISSION
TO TOYOTA L/C 4SPD TRANSFER CASE
1
1
51-7510
FORD NP435 4SP ADAPTER CASTING
2
1
51-7800
TOYOTA L/C-T18 4 SP CASTING
3
1
52-0226
TOY LC 16SP.X NV 23TH INTERNAL
4
**1**
52-3800 Modified
NP435 X DANA 300-23 MAIN SHAFT
52-3800 must be shortened 1" on the 23Spline end before shipping.
5
1
716306
L/C OUTPUT BEARING (NO SEAL)
6
1
716507
TOYOTA T.C. GASKET
7
1
716736
O-RING 157
8
6
723704
LOCK WASHER 3/8" ZINC
9
6
723721
H.H.C.S. 3/8"-16 X 1" PLATE GR5
10
2
724328
7/16"-14 X 1-1/4" H.H.C.S.
11
3
724329
7/16"-14 X 5-1/2" LG H.H.C.S.
12
4
725004
HEX NUT 1/2"-13 PLATED
13
4
725040
STUD BOLT 1/2"-13 X 2.0 LG
14
1
728701
NUT-NYLON LOCK 7/8"-16
15
1
728702
SPECIAL FLAT WASHER
