KIT CONSISTS OF:
No. Qty Part No. Description
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that
a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at
automotive dealerships and parts stores.
ADVANCE ADAPTERS INC. P/N: 50-6201
P.O. Box 247, 4320 Aerotech Center Way Old Part No: 711062-10
Paso Robles, CA 93447 PAGE 1 OF 3
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 04-04-13
OPTIONAL ITEMS:
Qty Part No. Description
FORD NP435 4SPD TRANSMISSION
TO TOYOTA L/C 3SPD TRANSFER CASE
1 716004 REAR MOUNT
1 716003 CROSSMEMBER
1 1 51-7510 FORD NP435 4SP ADAPTER CASTING
2 1 51-7800 TOYOTA L/C-T18 4 SP CASTING
3 1 52-0225 TOY LC 10SP.X NV 23TH INTERNAL
4 **1** 52-3800 Modified NP435 X DANA 300-23 MAIN SHAFT
52-3800 must be shortened 1" on the 23Spline end before shipping.
5 1 716306 L/C OUTPUT BEARING (NO SEAL)
6 1 716507 TOYOTA T.C. GASKET
7 1 716736 O-RING 157
8 6 723704 LOCK WASHER 3/8" ZINC
9 6 723721 H.H.C.S. 3/8"-16 X 1" PLATE GR5
10 2 724328 7/16"-14 X 1-1/4" H.H.C.S.
11 3 724329 7/16"-14 X 5-1/2" LG H.H.C.S.
12 4 725004 HEX NUT 1/2"-13 PLATED
13 4 725040 STUD BOLT 1/2"-13 X 2 LG
14 1 728701 NUT-NYLON LOCK 7/8"-16
15 1 728702 SPECIAL FLAT WASHER
