3 . The dowel pin must be shortened to 1.40" so that it is flush with the shortened governor housing.
4. Place the governor housing over the park gear into the
transmission case. Insert the dowel pin through the
governor housing, park spring and the park arm. Secure
the governor housing with the included 5/16"-18 flat head
cap screws and torque to factory specs.
5. Put a dab of silicone on the tip of each of the 3/8"-16 x 1.5"
studs and Loctite on the threads. Thread them into the steel
plate until they are just below, flush with the back side.
6. Press the included C-4 breather (#716061) into the steel
adapter plate (51-2902).
Dowel pin before modification
Shortened governor housing and dowel pin.
The 51-2902 steel plate after installing studs.
FORD C-4 TO ATLAS
TRANSFER CASE- SHORT
ADVANCE ADAPTERS INC. P/N: 50-2905
P.O. Box 247, 4320 Aerotech Center Way New Item: (3/04)
Paso Robles, CA 93447 PAGE 2 OF 4
Telephone: (800) 350-2223 Fax: (805) 238-4201 Page Rev. Date: 09-30-08
SPECIAL NOTE: The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components will
void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly recommend
that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We recommend that a
service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally available at automotive
dealerships and parts stores.
