Advance Adapters 713027-EK User Manual
Kit consists of
KIT CONSISTS OF:
No.
Qty
Part No.
Description
ADVANCE ADAPTERS INC.
P/N: 713027-EK
P.O. Box 247, 4320 Aerotech Center Way
Paso Robles, CA 93447
PAGE 1 OF 2
Telephone: (800) 350-2223
Fax: (805) 238-4201
Page Rev. Date:
01-31-14
SPECIAL NOTE:
The components packaged in this kit have been assembled and machined for specific type of conversions. Modifications to any of the components
will void any possible warranty or return privileges. If you do not fully understand modifications or changes that will be required to complete your conversion, we strongly
recommend that you contact our sales department for more information. This instruction sheet is only to be used for the assembly of Advance Adapter components. We
recommend that a service manual pertaining to your vehicle be obtained for specific torque values, wiring diagrams and other related equipment. These manuals are normally
available at automotive dealerships and parts stores.
TOYOTA LAND CRUISER 4 SPEED TO
CHEVY LS GEN 3 - MARK'S 4WD ADAPTORS
1
1
LC165473S
LUK CHEVY 11" (LOW-PRO)ASSYBLY
2
1
716673A
IN-LINE TEMP SENSOR KIT-1-3/8" X 1/2"NPTF
3
1
716314
T/0 BRG. LOW-DIAPH CLUTCH
4
6
716141A
GEN-3 FLYWHEELT BOLT 11MM
5
2
716039
SPACER-
FOR SLAVE CYLINDER
6
2
713124-PLT
TOYOTA L/C V8 SCAB PLT. FRAME
7
1KIT
713088
CHEVY LS1 UNIVERSAL MOUNT KIT
8
3
713039
SPACER BELLHOUSING MOUNT
9
1
713038
L/C BELLHOUSING MOUNT
10
1KIT
712525
L/C CHEV V8 CONV.KIT (MARKS)
11
1
712525-B
T/O BUSHING FOR 712525
12
1
711500M
FLYWHEEL GEN-3 VORTEC ENGINES
13
3
725002
LOCK WASHER 1/2" PLATED
14
6
723761
3/8"-16 X1" PRESSURE PLATE BOLT
15
2
723738
3/8"-16 X 2-3/4" H.H.C.S.
FOR SLAVE CYLINDER
16
2
723704
LOCK WASHER 3/8" ZINC
FOR SLAVE CYLINDER
17
3
720043
H.H.C.S. 12mm X 1.75TH X 70mm STRENGTH CLASS 8.8
18
6
720038
LOCK WASHER- 10MM
19
6
720028
10mm X 1.5 35mm LONG SHCS ZINC plated
20
2
720015
10mm FLAT WASHER
FOR SLAVE CYLINDER
